Description
GENERAL |
|
|---|---|
| Available | February 2020 |
| Dimensions | 131.0 x 99.9 x 76.2 mm (W x H x D) |
| Weight | 515 g (with Battery and Memory Card) |
| Colors | Black |
| Key features | 24.1MP APS-C sensor 4-stop optical image stabilization 4K movie recording Wi-Fi/Bluetooth connectivity DIGIC 8 image processor iTR AF intelligent tracking |
IMAGE SENSOR |
|
| Image sensor type | CMOS |
| Image sensor size | 22.3 mm x 14.9 mm APS-C |
| Resolution | 24.1MP |
| Image sensor features | 3:2 Aspect Ratio |
MONITOR |
|
| Monitor size | 3.0 Inch Clear View II TFT LCD |
| Monitor resolution | 1040k Dot |
| Articulation | Twist |
| Monitor features | 170-Degree Viewing Angle 7-Level Brightness Control 100% Coverage |
VIEWFINDER |
|
| Viewfinder type | Optical Pentamirror |
| Viewfinder coverage | 95% |
FOCUS |
|
| Focus type | Automatic Single Point AF Zone AF Large Zone AF |
| Focus mode | One Shot AF Servo AF Manual |
| Autofocus points | Up to 45-point |
| Focus features | Dual Pixel CMOS AF Phase Detection AF Predictive AF iTR AF Intelligent Tracking |
LENS |
|
| Focal length | 18-135mm |
| Aperture range | F3.5-F5.6 (Maximum) F22-F38 (Minimum) |
| Stabilization | 4-Stop Optical Image Stabilization |
| Lens features | 39cm Minimum Focus Distance EF/EF-S Mount 5-axis Digital IS |
EXPOSURE CONTROL |
|
| Metering modes | Partial Centre-Weighted Average Evaluative Spot |
| ISO sensitivity range | 100-25600 100-25600 (Auto) 51200 (Extended) |
| Video ISO sensitivity range | 100-12800 100-12800 (Auto) 25600 (Extended) |
| Shutter speed range | 1/4000s – 30s |
| Continuous shooting | Up to 7fps (with Viewfinder) Up to 7.5fps (with Live View) |
IMAGING |
|
| Imaging size | 6000 x 4000 (Max) |
| Aspect ratio | 3:2 4:3 16:9 1:1 |
| Imaging file types | JPEG RAW |
| Imaging features | 14bit RAW Digital Print Order Format Compliant sRGB & Adobe RGB Colour Space |
VIDEO |
|
| Video resolution | 3840 x 2160 @30/25/24fps 1920 x 1080 @60/50/30/25/24fps 1280 x 720 @60/50fps |
| Video recording limit | Up to 29 min 59 sec |
CONNECTIVITY & STORAGE |
|
| Wireless connectivity | Wi-Fi b/g/n Bluetooth 4.1 |
| Interface | USB HDMI mini 3.5mm Mic Input |
| Storage | SD SDHC SDXC |
| Connectivity features | UHS Speed Class 1 Compatible |
PLATFORM |
|
| Image processor | DIGIC 8 |
| Body | Aluminum Alloy Polycarbonate Resin Glass Fiber |
| Software | Photo Companion App PictBridge |
POWER |
|
| Battery | 1 x LP-E17 Rechargeable Li-Ion |
| Battery life | Up to 800 Shots (with Viewfinder) Up to 310 Shots (with Live View) |
